Uhome

FEATURE

Reliable LFP Cells

Safety Protection and Easy Move

Intelligent Build in BMS

High Inverter Compatibility

Easy Installation& After Sales Service

Digital monitoring system APP

>6,000 Cycles at 90% DOD

Scalable up to 24.5kW

LFP 6.14kWh

Nominal Capacity

6.14kWh

Size (L × W ×H)(mm)

650x210x410

Weight(pack)

66kg

Maximum Usable Capacity

5.6kWh

Rated Discharge/ Charge Current

7.2A

Nominal Dis-/Charge Power

3.07kW

Peak Power(Only Discharge)

6.14kW for 3s

Voltage

480-560Vd.c

Nominal Battery Operating Voltage

512V

Nominal Current

7.2A

Max. Battery Voltage

556V

DATASHEET

DETAILS
