FEATURE
LiFePO4 Safe Battery Chemistry
Easy Installation& After Sales Service
Box-in Mounted& Parallel & Series Connection
Intelligent Build in BMS
Safety Protection and Easy Move
>6000 Cycles at 90% DOD
LFP 2600HV
Total Energy*
2.56kWh
Usable Energy(DC)*
2.2kWh
Nominal Dis-/Charge Power
1.5kW
Constant Current(Only Discharge)
20A
Voltage
96~112Vd.c
Nominal Voltage
102.4Vd.c
Nominal Current
15A
Max. Charge Voltage
115.2Vd.c
Weight
27kg
Dimension(mm)
500*442*88mm
Warranty
10 years
DATASHEET
